Great capacity and unloading speed.

Categories: , Tags: ,


Loading volume: 32.500Lts – Capacity of load (wheat): 26T. Gauge: 2,785m. Length: 8,150m. Potency required: 150 HP (depends on terrain conditions). Axles: reinforced front axle with great manoeuvre capacity. Rear axle with adjustable position to reach more equilibrium during transport. Also it has detachable axle spindles. Unloading: by means of a 480mm diameter tube placed into a Ø510mm tube. Average unloading time: 3,5 to 4 minutes (approx.). Unloading tube folding: using a hydraulic cylinder also has a robust hinge and floating housing that permit a safety coupling. Unloading regulation: is made through a mechanic valve (guillotine type) hydraulically activated. Gearbox: made in steel with normalized gears in oil bath, effectuating the simultaneous driving of the vertical/horizontal augers by means of ASA 80-2 chains and heat treated sprockets - Relation 1:1 – 540RPM. Bodywork: welded and assembled by bolts and nuts. Tires size: four dish rims for size 24.5 x 32” tires
